Descripción
Delivery program
|
Product range
|
RMQ-Titan | ||
|
Basic function
|
Pushbutton actuators | ||
|
Single unit/Complete unit
|
Single unit | ||
|
Design
|
Flat | ||
| maintained | |||
|
Button plate
|
black | ||
|
button plate
|
|
||
| Blank | |||
|
Degree of Protection
|
IP66, IP67, IP69 | ||
|
Front ring
|
Metal Bezel | ||
|
Connection to SmartWire-DT
|
yes with SWD-RMQ connections |
||
| Front Dimensions | Ø= 36 x 3 mm | ||
Technical data
| General | |||
|
Standards
|
IEC/EN 60947 VDE 0660 |
||
|
Lifespan, mechanical
|
Operations | > 5 x 106 | |
|
Operating frequency
|
Operations/h | ≦ 3600 | |
|
Actuating force
|
n | ≦ 5 | |
|
Climatic proofing
|
Damp heat, constant, to IEC 60068-2-78 Damp heat, cyclic, to IEC 60068-2-30 |
||
|
Degree of Protection
|
IP66, IP67, IP69 | ||
|
Ambient temperature
|
|||
|
Open
|
°C | -25 – +70 | |
|
Storage
|
°C | – 40 – +80 | |
|
Mounting position
|
As required | ||
|
Mechanical shock resistance
|
15 Shock duration 11 ms Sinusoidal according to IEC 60068-2-27 g |
||
